This project is for Chevron in Nigeria, Africa. They need two On-Site NaOCl generator systems of 400 lbs/day. Since seawater is used, the output concentration from the two NaOCl generator systems is 0.2%. This is a two electrolyzer cells concept. Therefore, one cell will used as a stand by.
The block diagram of the system is shown below:
Specifications:
- NaOCl Generator System: 400 lbs/day x 2
- Application: FPSO (floating production storage and offloading)
- This is dual system concept. One system is used and the second is a stand-by.
- Inlet seawater flow rate: 20 to 22 GPM
- Input power: 480 VAC, 3 PH, 60 Hz
- PLC controlled power supply
- Storage tank: 1500 gallons
